An All Original 1955 Fender Tweed Champ Amplifier

This is an all original 6 watt 'tweed' narrow panel tube combo legend weighing just 12.00 lbs. The solid pine cabinet measures 12.25 inches wide x 11.00 inches high. The depth is 6.25 inches at the top expanding to 7.25 inches at the bottom. Three tubes (12AX7; 6V6GT; 5Y3GT), potentiometer stamped "304 524" (Stackpole June 1955), one six-inch Oxford Speaker with stamped code: "465-140" (Oxford 40th week of 1951), top control panel, two inputs, one volume knob, tweed covering, brown tweed-era grill. The letter code on the tube-chart is EI (E= 1955 and I = September). The serial number C00101 has been written on the tube-chart and also stamped onto the chassis. The tweed covering is remarkably clean and the original leather handle is in good shape. A wonderful little fifty-year old legend… just turn it up for real tube gain at a reasonable volume.

"With its three-tube circuit, it represents the simplest of all amplifier designs, and yet its performance is such that it has long been a favorite with collectors and players, despite its tiny 3W output.

At the time, its normal undistorted output would have been considered quite loud enough by the student players it was aimed at. Later its appeal to players lay in the fact that it could be made to distort at comparitively low levels and then fed either to a PA or a larger amplifier. The fact that its most appealing quality was an accident of design rather than a feature is a paradox to which we will return.

Distortion in an amplifier is, fundementally, the sound of circuitry in distress. In particular, it arises when one amplifying stage expects the next stage to produce more output than it is capable of supplying. When the Champ was designed and marketed for use with the low-powered guitar pickups of the day, the level of amplification provided by its single pre-amp tube was not enough to "overdrive" its single power output tube. Later, with more powerful pickups, higher signal levels would pass through the pre-amp tube, demanding ever more amplification and volume from the power output tube.

Fortunately for lovers of the overdriven sound, it was quite incapable of supplying the output levels required, and the distortion was the result. To a greater or lesser extent, all of Fender's early amplifiers display the same characteristic, although as their power increases the point at which the distortion sets in moves further back. Of course by modern standards they were all tiny amplifiers, rarely putting out more than 15W, and then into speakers that were simply not capable of taking the power, another (though much less sustainable) source of distortion." (John Morrish The Fender Amp Book, pp. 12-13).
